General Information
Seating Capacity | Stage Dimensions | Stage Features |
827 Total Fixed Seats | 98x38 Full Stage | Both Theatrical & Acoustical Setups |
273 Orchestra | 54'x10' Pit Cover w/ Curved Front Edge | 8' Deep Pit w/ Removable Cover |
231 Mezzanine | 25'x27' 4" Proscenium Opening | Full Backstage Crossways & Access |
323 Balcony | 20'x38' Stage Right Wing | Modified Fly System |
10 Handicap Accessible Seats | 24'x38' Stage Left Wing | Black Matte Finished Sprung Floor |
Technical Information
Lighting | Sound | Video |
4 - 5 degree lens | 8 - Shure Wireless ULXD Channels | 1 - 23.5'x13' Motorized Screen |
4 - 10 degree lens | ----- 4 SM58 Handhelds | 1 - Panasonic DZ16K2 Projector |
22 - 19 degree lens | ----- 8 WL93 Bodypacks | 2 - Denon 500BD Blu-Ray Players |
24 - 26 degree lens | 3 - Innovox HLA-16 Main Speakers | 5 - Panasonic PTZ AW-UE150 Cameras |
20 - 36 degree lens | 3 - Innovox HLA-9 Delay Speakers | 1 - Blackmagic 20x20 Video Hub |
6 - 50 degree lens | 5 - Innovox HLA Front Fill Speakers | Video Monitoring Locations: |
10 - S4 750 Dimmer Packs | 1 - Innovox Custom Sub Speaker | -----55" Lobby x 2 |
28 - ETC Colorsource Pars | 3 - QSC K10 Stage Monitors | -----55" Stage Right Wing |
31 - ETC Series 1 Luster + Lekos | 2 - Denon 700R Audio Recorder | -----32" Stage Left Wing |
26 - ETC S4WRD Color Lekos | 3 - Whirlwind 8x4 50' Snake | -----32" Green Room x 2 |
30 - Altman Spectra Cyc 100 | 4 - Wired Clear-Com Headsets | 3 - Presentation Connection Locations: |
1 - Lycian 1271 Followspot | 5 - Wireless Clear-Com Headsets | -----Control Room Rack |
4 - Electrics Overstage | 2 - Clear-Com Rack Stations | -----FOH A/V Rack |
34 - ETC D40 Studio Pars (Shell) | Audio Monitoring in all support areas | -----Downstage Left |
18 - DMX Gateway Connections | Various Mics, Stands, XLR Cables | 1 - Blackmagic Video Production Booth |
Rigging | Controls | Additional Specs |
Fly Rail Stage Right at Stage Level | Audio/Video | Batten Low Trim 3' 6" |
Loading Bridge at Grid | -----Yamaha QL 5 Console | Batten High Trim 43' 8" |
29 Total Single Purchase Line Sets | -----Crestron Touchscreen in Booth | All Pipe is 1 1/2" ID Schedule 40 Pipe |
2 - Side Tabs (15'+11' on each side) | -----Crestron Touchscreen SR | Scene Shop/Loading 20' from Stage |
16 - Open Battens (64', 1865lb max) | Lighting | Stage Overhead Door 10'x10' |
12 - Designated Battens | -----ETC Element 2 EOS Console | Addition Equipment Available |
-----3 Acoustical Clouds (64") | -----Paradigm Touchscreen in Booth | -----200 Black Musician Chairs |
-----4 Electrics (64", 2425lb max) | -----Paradigm Touchscreen SR | -----15 Padded Arm Chairs |
-----1 Gray Main Valance (10'x64') | -----Button Station at all entrances | -----150 Music Stands |
-----1 Gray Main Drape (21.5'x73') | Portable Control on iPad | -----Conductor Podium & Stand |
-----1 Midstage Traveler (21.5'x73') | -----iPad Blackmagic Video Hub App | -----Lectern Podium |
-----1 Upstage Traveler (21.5'x64') | -----Yamaha Mixing App | -----12 Stage Platforms (4'x8') |
-----1 White Cyclorama (22.5'x64') | -----Creston App | -----10 Choral Risers (4 step) |
Drapery Available: | -----ETC Paradigm App | -----9 ft Steinway Grand Piano |
-----4 Black Boarders (8'x96') | -----ETC Button App | -----6 ft Yamaha Baby Grand Piano |
-----4 Black Legs (21.5'x18') | -----ETC Console App | -----Yamaha Upright Piano |
-----8 Black Legs (21.5"x12') | -----ETC Radio Remote Focus Unit | -----Holiday Décor Nov-Dec |
